Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.
|
|
|
|
|
|
|
|
Generator Set Specifications
- Maximum Rating
- 2,250 kVA
- Minimum Rating
- 2,000 kVA
- Emissions/Fuel Strategy
- Low Fuel Consumption
- Voltage
- Voltage - Low (415 Volts), Medium and High Voltage
- Frequency
- 50 Hz
- Speed
- 1,500 rpm
- Duty Cycle
- Standby, Prime
Engine Specifications
- Engine Model
- 3,516B TA, V-16, 4-Stroke Water-Cooled Diesel
- Bore
- 6.69 in
- Stroke
- 7.48 in
- Displacement
- 4,210.6 in
- Compression Ratio
- 14.0:1
- Aspiration
- TA
- Fuel System
- Electronic unit injection
- Governor Type
- Adem™3
Standard Equipment:
-
- Cooling
-
- Radiator or heat exchanger
-
- Control Panel
-
- EMCP 4.2
- EMCP 4.2
Optional Equipment:
Specifications
Generator Set Specifications
- Maximum Rating
- 2,250 kVA
- Minimum Rating
- 2,000 kVA
- Emissions/Fuel Strategy
- Low Fuel Consumption
- Voltage
- Voltage - Low (415 Volts), Medium and High Voltage
- Frequency
- 50 Hz
- Speed
- 1,500 rpm
- Duty Cycle
- Standby, Prime
Engine Specifications
- Engine Model
- 3,516B TA, V-16, 4-Stroke Water-Cooled Diesel
- Bore
- 6.69 in
- Stroke
- 7.48 in
- Displacement
- 4,210.6 in
- Compression Ratio
- 14.0:1
- Aspiration
- TA
- Fuel System
- Electronic unit injection
- Governor Type
- Adem™3
Standard/Optional Features
Standard Equipment:
-
- Cooling
-
- Radiator or heat exchanger
-
- Control Panel
-
- EMCP 4.2
- EMCP 4.2
Optional Equipment:
